CNC Milling Machines with CAD/CAM by vhf Germany
vhf Germany are known for their extensive experience in Computer Aided Manufacturing since 1988. vhf develops and manufactures CNC milling machines in many dimensions, software and a wide range of tools. They don’t like to compromise on quality and hence vhf applies a quality management system according to the standard DIN ISO 9001: 2015.
vhf displayed a wide range of CNC Milling Machines at UAE International Dental Conference & Arab Dental Exhibition. Speaking to dentistchannel.online the product specialist from vhf gave a demonstration of how these Milling Machines work.
N4- WET GRINDING WITHOUT COMPROMISE
N4 is a compact wet grinding machine without an external unit for grinding respectively milling blocks of glass ceramics, zirconium oxide and composites as well as titanium abutments. Its highest precision and the quick drive units – common characteristics of all vhf machines – are combined here with a closed liquid cooling system in an extremely compact housing.
Features:
Exceptional Precision– restorations in ultra HD, premium spindle with 4-fold hybrid ceramic ball bearings for maximum running smoothness, 3 microns repetition accuracy.
Sophisticated Design– eight fluid nozzles for even tool cooling, high speeds up to 60,000 RPM, heavy industrial quality.
Absolute Independence– 30 block materials from 12 manufacturers – and rising, >140 titanium and CoCr prefabricated abutments from 11 manufacturers, ideal for the laboratory and the practice lab.
Validated Results – ideal for the laboratory and the practice lab
Maximum Economy– work on up to three blocks at the same time, automatic changer for eight tools, worry-free 24-month warranty
DRY MILLING WITH A PLUS. K5+
Proven quality now even better: with the new K5+ you will achieve perfect dry milling results. Process an especially wide range of indications and material (blanks up to40 mm) with 5 axes. Revolutionary technology, such as a tool-free blank clamping and a built-in ionizer will help you in doing so.
Features:
Unparallel Precision– restorations in ultra HD, premium spindle with 4-fold hybrid ceramic ball bearings for highest running accuracy, 3 microns repetition accuracy.
Powerful and Robust– mills the toughest materials on the market, incl. CoCr, powerful 500-watt spindle and 60,000 rpm, heavy industrial quality for maximum stiffness, solid cast body for the lowest vibrations.
Maximum Independence– unlimited material accessibility in 98 mm disc format, separate block and prefab abutment holders available, covers the broadest range of indications, due to ± 35° rotation angle in the 5th axis, and up to 40 mm blanks.
Proven German Reliability– 100% engineered and manufactured in Germany, sophisticated sealing air concept to protect mechanics, electronics, and spindle, webcam for remote support, ethernet for stable long-range connection, worry-free 24-month warranty.
Extremely Economical– ionizer and improved air circulation for easy machine cleaning, DirectDiscTechnology for revolutionary disc clamping, automatic changer for 16 tools, easy to operate DentalCAM with DirectMill function included no annual fees.
S2- PERFORMANCE NONSTOP
The S2 is a highly versatile dental milling machine. It has five simultaneously working axes, a blank changer for 8 blanks and is designed for dry machining as well as for wet machining. S2 is prepared for connecting the wet grinding module. Thus, you can grind all common glass ceramic types.
Features:
Maximum Precision– restorations in ultra HD, premium spindle with precision bearing, a powerful 600 watts and 60,000 RPM, 3 microns repetition accuracy.
Tremendous Stability– processes all types of commonly used materials, including CoCr as well as titanium and glass-ceramics with the wet-grinding option, solid cast-body for minimum vibrations.
Maximum Variety– almost unlimited choice of materials in 98 mm disc format as well as 30 types of blocks and >140 prefabricated titanium and CoCr abutments, large indication diversity thanks to a ± 30-degree rotation angle in the 5th axis, and up to 30 mm blanks, the optional wet-grinding module converts the S2into a wet-processing machine without need for modifications.
High Reliability– day and night operation, 100% developed and manufactured in Germany, worry-free 24-month warranty.
Maximum Efficiency- automatic changer for 8 discs or 24 blocks or 48 prefabricated abutments, automatic changer for 16 tools, easy to operate DentalCAM with DirectMill function – no annual fees.
K4 EDITION- AMAZING RESULTS. AFFORDABLE PRICE
Most obvious is the extremely compact design of the K4 edition. Upon closer examination, the uncompromisingly rigid construction of the machine leaps to the eye. So, it is ensured that you will achieve first-class results – even in extremely hard non-precious alloys on cobalt-chrome basis. The K4 edition is our special edition for the fifth K4 anniversary with new features.
Features:
Maximum Features: restorations in ultra HD, high-quality spindle with 4-point bearing for maximum concentricity accuracy, 5 microns repetition accuracy, high rotational speeds of up to 60,000 RPM, automatic axis calibration.
Powerful Construction: processes zirconia, composites and plastics as well as CoC, an uncompromisingly robust build with extremely compact dimensions, four axes working simultaneously for high indication diversity.
Complete Independence– almost unlimited availability of materials in 98 mm disc format, up to a thickness of 25 mm; no restrictions in terms of the material manufacturer
High Reliability– 100% developed and manufactured in Germany, tactile measuring pin for use of diamond tools, worry-free 24-month warranty, thousands of machines in use world-wide.
Maximum Efficiency– automatic changer for seven tools, best price-performance ratio, easy to operate DentalCAM with DirectMill function included – no annual fees.
